Aluminum

Aluminum

  • Aluminum (symbol: Al) is a chemical element in the boron group with the atomic number 13.
  • It is a silvery-white, lightweight, and soft metal with excellent corrosion resistance and thermal conductivity.
  • Aluminum is the third most abundant element (after oxygen and silicon) and the most abundant metal in the Earth's crust, making up about 8% of the crust by weight.

2. Properties:

  • Lightweight: Aluminum has a low density, about one-third that of steel, making it ideal for applications where weight reduction is crucial, such as aerospace and automotive industries.
  • Corrosion Resistance: Aluminum forms a thin, protective oxide layer when exposed to air, providing excellent corrosion resistance, especially in marine and corrosive environments.
  • Conductivity: Aluminum is an excellent conductor of heat and electricity, making it widely used in electrical transmission lines, heat exchangers, and electronic devices.
  • Malleability and Ductility: Aluminum is highly malleable and ductile, allowing it to be easily formed into various shapes and sizes through processes such as rolling, extrusion, and forging.
  • Reflectivity: Aluminum has high reflectivity for both visible light and thermal radiation, making it suitable for applications such as mirrors, solar panels, and heat shielding.
  • Recyclability: Aluminum is 100% recyclable without any loss of quality, and recycling aluminum requires only a fraction of the energy needed to produce primary aluminum, making it an environmentally friendly material.

3. Applications:

  • Transportation: Aluminum is extensively used in the automotive, aerospace, and marine industries for lightweight structural components, such as body panels, chassis, wheels, and aircraft fuselages, to improve fuel efficiency and performance.
  • Packaging: Aluminum is widely used for packaging materials, including cans, foils, and containers, due to its lightweight, corrosion resistance, and ability to preserve the freshness of food and beverages.
  • Construction: Aluminum is used in construction for windows, doors, roofing, curtain walls, and structural components due to its durability, corrosion resistance, and ease of fabrication.
  • Electrical Transmission: Aluminum conductors are used in electrical transmission lines and power cables due to their high conductivity, lightweight, and cost-effectiveness compared to copper.
  • Consumer Goods: Aluminum is used in various consumer products, including cookware, utensils, furniture, and sporting equipment, due to its lightweight, durability, and aesthetic appeal.
  • Industrial Applications: Aluminum is used in a wide range of industrial applications, including heat exchangers, chemical processing equipment, machinery components, and storage tanks, due to its corrosion resistance and thermal conductivity.

4. Aluminum Alloys:

  • Aluminum is often alloyed with other elements to enhance its properties for specific applications.
  • Common alloying elements include copper, silicon, magnesium, manganese, and zinc.
  • Aluminum alloys exhibit a wide range of mechanical properties, corrosion resistance, and workability, making them suitable for diverse applications ranging from aerospace to automotive industries.

Aluminum's unique combination of properties, including lightweight, corrosion resistance, conductivity, and recyclability, makes it one of the most versatile and widely used metals in the world, impacting almost every aspect of modern life.

Alloy Chemical Composition (%) Mechanical Properties
Alloy 2024 Copper: 3.8-4.9 Tensile Strength: 470 MPa<br>Yield Strength: 325 MPa<br>Elongation: 20%<br>Hardness (Brinell): 120
Manganese: 0.3-0.9
Magnesium: 1.2-1.8
Silicon: 0.5
Zinc: 0.25
Alloy 6061 Magnesium: 0.8-1.2 Tensile Strength: 310 MPa<br>Yield Strength: 276 MPa<br>Elongation: 12%<br>Hardness (Brinell): 95
Silicon: 0.4-0.8
Iron: 0.7
Copper: 0.15-0.4
Zinc: 0.25
Titanium: 0.15
Alloy 7075 Zinc: 5.1-6.1 Tensile Strength: 570 MPa<br>Yield Strength: 503 MPa<br>Elongation: 11%<br>Hardness (Brinell): 150
Magnesium: 2.1-2.9
Copper: 1.2-2.0
Chromium: 0.18-0.28
Others: 0.2 max
Alloy 5083 Magnesium: 4.0-4.9 Tensile Strength: 330 MPa<br>Yield Strength: 240 MPa<br>Elongation: 12%<br>Hardness (Brinell): 75
Manganese: 0.40
Chromium: 0.05-0.25
Iron: 0.4
Others: 0.15 max

Notes:

  • Tensile strength is the maximum amount of tensile (stretching) stress a material can withstand before breaking.
  • Yield strength is the amount of stress at which a material begins to deform plastically.
  • Elongation is the percentage increase in length of a material before it fractures.
  • Hardness (Brinell) is a measure of a material's resistance to indentation or scratching.
